Lenovo ThinkStation P5 Intel Xeon W w3-2425 32 GB DDR5-SDRAM 1 TB SSD NVIDIA T1000 Windows 11 Pro for Workstations Tower Workstation Black, Red

SKU#: 30GA004MUS  | UPC#: 0197531641144

Regular price $8,339.00
Sale price $8,339.00 Regular price $0.00
Sale Sold out
Shipping calculated at checkout.
Only 1 units left
Secure checkout with Payment methods
  • Apple Pay
  • Discover
  • Google Pay
  • Mastercard
  • Visa

View Product Details

Lenovo ThinkStation P5 30GA004MUS Workstation - 1 Xeon w3-2425 - vPro Technology - 32 GB - 1 TB SSD - Intel W790 Chip - Windows 11 Pro for Workstations - 1 8 GB Graphics - NVMe, Serial ATA Controller - English Keyboard - Gigabit Ethernet - Wireless LAN

ThinkStation P5

Powered for modern businesses, the brand-new ThinkStation P5 features dependable power, performance and security at its best. The up to 1 Intel Xeon W-2400 series processor supports up to 24 cores and delivers top-notch productivity in any workspace. Its HD Realtek audio and 1.5W speaker
bring massive, detailed soundstage that takes online streaming and conferencing to the next level. Security features, including the Discrete TPM 2.0 chip, Kensington security slot and chassis intrusion switch provide end-to-end protection against device and data theft.

Whether working from remote job locations or a corporate space, the Intel Wi-Fi 6E feature enables consistent speed and strong bandwidth at all times. The front and rear connectivity ports, including USB-C 3.2 Gen 2 allow seamless data transfer and connectivity to monitors and peripherals.

With up to 512GB DDR5 memory support and up to 4TB storage, this workstation lets users multitask and switch between applications without having to worry about performance and speed.

It has up to 512 DDR5 GB memory, supports up NVIDIA RTX A6000 graphics, up to 1 Intel Xeon processor as well as up to 4TB SSD storage, which make it a powerful workstation that breezes through compute-intensive tasks or heavy-duty applications easily.

Lenovo ThinkStation P5 Intel Xeon W w3-2425 32 GB DDR5-SDRAM 1 TB SSD NVIDIA T1000 Windows 11 Pro for Workstations Tower Workstation Black, Red
Processor
Processor manufacturer
Intel
Processor family
Intel Xeon W
Processor model
w3-2425
Processor cores
6
Processor threads
12
Processor boost frequency
4.4 GHz
Processor frequency
3 GHz
Performance cores
6
Performance-core Max Turbo Frequency
4.4 GHz
Processor cache
15 MB
Processor cache type
Smart Cache
PCI Express slots version
4.0, 5.0
Processor socket
LGA 4677 (Socket E)
Processor base power
130 W
Maximum turbo power
156 W
Memory
Internal memory
32 GB
Maximum internal memory
512 GB
Internal memory type
DDR5-SDRAM
Memory layout (slots x size)
2 x 16 GB
Memory slots
8x DIMM
Memory clock speed
4800 MHz
ECC
Yes
Non-ECC
No
Memory channels
Quad-channel
Storage
Total storage capacity
1 TB
Storage media
SSD
Optical drive type
No
Number of storage drives installed
1
Total SSDs capacity
1 TB
Number of SSDs installed
1
SSD capacity
1 TB
SSD interface
PCI Express 4.0
NVMe
Yes
SSD form factor
M.2
M.2 SSD size
2280 (22 x 80 mm)
Card reader integrated
Yes
Graphics
Discrete graphics card
Yes
Discrete GPU manufacturer
NVIDIA
On-board graphics card
No
Discrete graphics card model
NVIDIA T1000
Discrete graphics card memory
8 GB
Number of discrete graphics cards
1
On-board graphics card model
Not available
Network
Ethernet LAN
Yes
Ethernet LAN data rates
10,100,1000 Mbit/s
LAN controller
Intel® I219-LM
Wi-Fi
Yes
Top Wi-Fi standard
Wi-Fi 6E (802.11ax)
Wi-Fi standards
802.11ad, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
WLAN controller manufacturer
Intel
WLAN controller model
Intel Wi-Fi 6E AX211
Antenna type
2x2
Bluetooth
Yes
Bluetooth version
5.1
Wake-on-LAN ready
Yes
Ports & interfaces
USB 2.0 ports quantity
2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
5
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
2
USB 3.2 Gen 2x2 Type-C ports quantity
1
Ethernet LAN (RJ-45) ports
1
Line-out
Yes
Line-in
Yes
Combo headphone/mic port
Yes
Design
Chassis type
Tower
Volume
33 L
Placement supported
Vertical
Product colour
Black, Red
Performance
Motherboard chipset
Intel W790
Built-in speaker(s)
Yes
Password protection
Yes
Password protection type
Power on, Supervisor
BIOS type
UEFI
Trusted Platform Module (TPM)
Yes
Product type
Workstation
Trusted Platform Module (TPM) version
2.0
Software
Operating system architecture
64-bit
Operating system language
English
Operating system installed
Windows 11 Pro for Workstations
Processor special features
Intel® Turbo Boost Max Technology 3.0 frequency
4.4 GHz
Intel® Turbo Boost Technology
3.0
Power
Power supply
1000 W
80 PLUS certification
80 PLUS Platinum
Operational conditions
Operating temperature (T-T)
10 - 35 °C
Storage temperature (T-T)
-40 - 60 °C
Operating relative humidity (H-H)
20 - 80%
Storage relative humidity (H-H)
10 - 90%
Operating altitude
0 - 3048 m
Non-operating altitude
0 - 12192 m
Certificates
Compliance certificates
RoHS
Certification
TCG certified, FIPS 140-2 certified, TCO Certified 9.0
Sustainability
Sustainability certificates
ENERGY STAR, EPEAT Gold, TCO
Weight & dimensions
Width
165 mm
Depth
453.9 mm
Height
446 mm
Weight
24.5 kg
Packaging content
Mouse included
Yes
Mouse connectivity
Wired
Keyboard included
Yes
Display
Display included
No
Keyboard
Keyboard connectivity
Wired
Keyboard layout
QWERTY
Audio
Audio chip
Realtek ALC897-Q
Audio system
High Definition Audio
Number of speakers
1
